Technical Area

Wall Hung
Basin


As per shown in the picture, the rag bolt must be grouted into the cement/concrete wall. The bolts must be fixed to the cement/concrete wall. Allow setting & checking than install it using nut and washer.

Counter
Washbasin

At the beginning

  • A skilled or experienced person should install counter lavatories.
  • Avoid using adhesive with this product.
  • Check the waste area and supply tubing if required.
  • Do not open the lavatory from its protective carton until you are ready for installation.
  • Please follow all local building and plumbing codes.

Material &
Tools


Measure tape, Keyhole or saber saw, Hammer, Glasses, Rags or Paper toweling, Drill (1/2 dia, drill bit or larger), Pencil, sealant, sharp knife or scissors.

Installation of
Lavatory

Please Note: Please install it in a way that future removal from underneath the counter top is possible without damaging the counter top.

  • Please check the desired location for clearance between the back splash, faucet and cabinet.
  • Please cut the template.
  • Please carefully trace the template on the counter top directed.
  • Please mark the faucet hole centerline on the counter top.
  • Please drill a 1/2" pilot on the inside of the cut line.

For wood
Counter tops


  • Mark and per-drill the wood screw holes at the locations shown on the template.
  • Waterproof any exposed areas of wood.

For Marble
Counter tops


  • Position the counter top upside down on foam padding to protect the surface.
    Mark and drill 3/6" holes 5/8" deep at the locations shown on the template.
  • Use a setting tool and hammer to secure the anchors.

For All
Installations


  • If the counter top has not been installed, install it at this time.
  • Drill the faucet holes according to the faucet installation instruction.
  • Install the faucet to the counter top according to the manufacture's instructions.
  • Install the drain to the lavatory according to the manufacture's instructions.
